Round Cutting Capacity
90°: 12.6"
60° Left: 12.6"
60° Right: 12.6"
75° Left: 12.6"
75° Right: 12.6"
45° Left: 12.6"
45° Right: 12.6"
30° Left: 7.8"
Minimum: 0.78"
Rectangle Cutting Capacity
90°: 20.4" x 12.6"
75° Left: 20.4" x 12.6"
75° Right: 19.2" x 12.6"
60° Left: 18.5" x 12.6"
60° Right: 16.5" x 12.6"
45° Left: 7.8" x 12.6"
45° Right: 12.9" x 12.6"
30° Left: 7.8" x 12.6"
Minimum: 0.78" x 0.78"
Saw Blade Dimensions: 17'5" x 1-1/4" x .042"
Working Height: 31.5"
Cutting Speed: 49 - 360 SFM
Stroke of Feeding Gripper: 118"
Minimum Remnant Length: 5.9"
Equipped With:
Behringer CNC-Dialogue Touchscreen Control
Powered Infeed Roller Conveyor w/ Integrated Gripper
Spray Mist Cooling
F.O.B Chicagoland Area
Disclaimer
Preliminary specifications are provided for general guidance only and may change without notice.
They are believed to be accurate but are not guaranteed. All specifications, dimensions, capacities,
weights, and performance figures should be independently verified by the buyer prior to purchase or use.
Bridgeline Machinery Corp. makes no representations or warranties, express or implied, regarding the completeness,
accuracy, or suitability of any machine specifications, and shall not be liable for any errors or omissions.
